Di Do - 2 x t
CR 0,5x Di
SF acc. to specification
DH CRi
THi SF + DH
Legend Hemisperical head
t = wall thickness
Do = outside diameter
Di = inside diameter
CR = crown radius
KR = knuckle radius
SF = straight flange height
DH = dished height
THi = total height inside
